LINETRAXX® SmartDetect RCMS410
LINETRAXX® SmartDetect RCMS410 Variant(s)
| Type | Supply voltage US | Measuring-current transformers that can be used | Configurable at the factory | Enabled function modules* | Art. No. | |
|---|---|---|---|---|---|---|
| RCMS410-24 | DC 24 V | Type A / Type F | (Type B / Type B+) with function module B | Factory settings**, function modules | Customised (A, B, C can be bought later) | B84604040 |
| RCMS410-24 | DC 24 V | Type A / Type F | Type B / Type B+ | - | B (A and C can be bought later) | B84604041 |
| RCMS410-24 | DC 24 V | Type A / Type F | Type B / Type B+ | - | A, B, C | B84604042 |
* Function modules: A: Harmonic analysis (FFT) / B: AC/DC sensitive measuring and evaluation of values / C: Connection of type A external current transformers
** As part of the ordering process, customer-specific factory settings can be defined together with our sales department for some parameters (e.g. response values and interface settings) with which the units are delivered. The reference to a customer-specific configured variant can then be found on the packaging of the individual product as well as in the delivery note (the changed parameters are listed there, the assignment is made via the item number in the delivery note and the serial number of the unit).
Optional Accessories for LINETRAXX® SmartDetect RCMS410
Power supply units
| Type | max. connected current transformers | Art. No. |
|---|---|---|
| STEP-PS/1 AC/24 DC/0.5 | 4 | B94053110 |
| STEP-PS/1 AC/24 DC/1.75 | 14 | B94053111 |
| STEP-PS/1 AC/24 DC/4.2 | 34 | B94053112 |
Measuring current transformers
| Type |
|---|
| CTUB100 series |
| CTBS25 |
| CTAC series |
| W…-S… series |
| WR…S(P)series |
| WS series |
| WS…S series |
Downloads for LINETRAXX® SmartDetect RCMS410
| Category | Language | Name | Size | Timestamp | D-/B-Number |
|---|---|---|---|---|---|
| Technical information | Länderliste Funkzulassungen/Countries with RF Approval | 55.3 KB | 2025/04/11 10:03:0911.04.2025 10:03:09 | ||
| Declarations of Conformity | UKCA - RCMS410 | 131.6 KB | 2025/01/28 08:00:4428.01.2025 08:00:44 | ||
| Datasheets | DE | RCMS410 | 8.7 MB | 2025/06/02 06:24:2802.06.2025 06:24:28 | D00424 |
| Datasheets | EN | RCMS410 | 8.7 MB | 2025/06/02 06:25:4802.06.2025 06:25:48 | D00424 |
| Manuals | DE | RCMS410 | 6.9 MB | 2025/06/04 05:38:4404.06.2025 05:38:44 | D00424 |
| Manuals | EN | RCMS410 | 6.8 MB | 2025/06/04 05:39:4704.06.2025 05:39:47 | D00424 |
| Quickstarts | DE | RCMS410 | 1.1 MB | 2025/03/17 08:28:4917.03.2025 08:28:49 | D00424 |
| Quickstarts | EN | RCMS410 | 1.1 MB | 2025/03/17 08:28:4917.03.2025 08:28:49 | D00424 |
| Technical information | EN | Software information | 271.7 KB | 2025/09/24 13:04:4724.09.2025 13:04:47 | |
| CE Declarations of conformity | RCMS410 | 99.1 KB | 2025/01/27 07:02:1927.01.2025 07:02:19 |
