Electrical safety in machine tool manufacturing

The new EN ISO 14120

The new EN ISO 14120 affects nearly all machine manufacturers. This machinery directive states that the safety objectives of the low voltage directive must be complied with. Bender supports this by providing the appropriate monitoring equipment. Fire safety in machines is often neglected, but forms part of the statutory safety strategy requirements. This is guaranteed by the Bender RCM range.

Product overview ISOMETER®
Product overview Residual current monitoring
Technical paper Insulation fault location - Planning and set up in the solar charging station at the University of Applied Sciences Bingen
Technical paper Electrical safety in control and auxiliary circuits
Technical paper Tvilum alias IKEA trusts in BENDER

Recommended systems for insulation monitoring:

Recommended systems for insulation fault location:

Recommended systems for residual current monitoring:

Recommended measuring current transformers:

Analysing and reporting:

EN 61557-8
Electrical safety in low voltage distribution systems up to 1 000 v a.c. and 1 500 v d.c. - Equipment for testing, measuring or monitoring of protective measures - Part 8: Insulation monitoring devices for IT systems

EN 61557-9
Electrical safety in low voltage distribution systems up to 1000 V a.c. and 1500 V d.c. - Equipment for testing, measuring or monitoring of protective measures - Part 9: Equipment for insulation fault location in IT systems

EN 61557-15
Electrical safety in low voltage distribution systems up to 1000 V ac and 1500 V dc - Equipment for testing, measuring or monitoring of protective measures - Part 15: Functional safety requirements for insulation monitoring devices in IT systems and equipment for insulation fault location in IT systems

IEC 60204-1
Safety of machinery - Electrical equipment of machines - Part 1: General requirements
